SOUND GENERATORSound GeneratorSuperNATURAL Piano
ZEN-CoreMax. Polyphony256TonesPiano: 38 tones
E.Piano: 34 tones
Strings: 36 tones
Organ/Pad: 184 tones
Synth/Other: 726 tones (including 74 drum sets)AmbienceType: Studio, Lounge, Concert Hall, Cathedral
Depth: 10 typesKEYBOARDKeyboard88 keys (PHA-4 Standard Keyboard: with Escapement and Ivory Feel)SPEAKER SYSTEMSpeakersSpeakers: 12 cm (4-3/4 inches) x 2 (with speaker box)Rated Power Output11 W x 2HEADPHONESHeadphones3D AmbienceBLUETOOTHBluetoothBluetooth Ver 4.2
Profile: A2DP (Audio), GATT (MIDI over Bluetooth Low Energy)
CODEC: SBC (Supports SCMS-T content protection)AUTOMATIC ACCOMPANIMENTStylePreset: 177 styles
*Need to update to Ver1.10ControlsStart/Stop, Intro/Ending, Sync Start. Variation1, Variation2, Interactive functionChord SequencerPreset Chord Pattern: 140 types
User Chord Pattern: 256
*Import / export possibleSCENEScenePreset: 107 styles
User Scene: 256
*Import / export possibleDATA PLAYBACKAudio FileWAV: 44.1 kHz, 16-bit linear format
MP3: 44.1 kHz, 64 kbps--320 kbpsRECORDERAudio FileWAV: 44.1 kHz, 16-bit linear format
Songs: 200
Recording time per song: 200 minutes (approx. 1.9 GB)
Total recording time: 390 minntes (approx. 3.8 GB)Recording SystemNew Song Recording
Overlapping Recording
INTERNAL SONGSInternal Songs3 SongsTUNING, VOICINGTouch SensitivityKey Touch: 100 types, fixed touch
Hammer Response: Off, 10 typesMaster Tuning415.3--466.2 Hz (adjustable in increments of 0.1 Hz)Temperament10 types (Equal, Just Major, Just Minor, Pythagorean, Kirnberger I, Kirnberger II, Kirnberger III, Meantone, Werckmeister, Arabic), selectable temperament keyEffectsAmbience
Equalizer (3-band digital equalizer)
Only for organ tones:
Rotary Speaker EffectMic EffectsAuto Harmony (9 types)
Voice Transformer (Octave: -1--+1, Formant: -12--+12 semitones)
Vocal Designer (Type: 26 types, Tone; 26 types)
Compressor (Type: Soft, Normal, Hard)
Noise Suppressor (Threshold: -96--0 dB)Piano DesignerLid
String Resonance
Damper Resonance
Key Off Resonance
Cabinet Resonance
Single Note Tuning
Single Note Volume
Single Note CharacterCONVENIENT FUNCTIONSConvenient FunctionsMetronome (adjustable Tempo/Beat/Down beat/Pattern/Volume/Tone)
Transpose (Keyboard/Style: in semitones)
Favorite Tone (50 tones)
Dual
Split (split point adjustable)
Twin Piano
Demo Song
Center Cancel
Auto Off
One Touch PianoOTHERDisplayGraphic LCD 160 x 160 dotsControlMaster Volume slider
Accompaniment Volume slider
Song Volume sliders
Mic Volume slider
Mic Gain knob
Assignable Wheel x 2ConnectorsDC In jack
Pedal1 (Damper) jack (capable of continuous detection when optional pedal connected)
Pedal2 (Damper, Sostenuto, Soft) jacks (capable when dedicated pedal board connected)
Input Stereo jack: Stereo miniature phone type
Output (L/Mono, R) jacks: 1/4-inch phone type
Mic Input jack: 1/4-inch phone type
USB Computer port: USB B type (supports USB MIDI/AUDIO)
USB Memory port: USB A type
Phones jack x 2: Stereo miniature phone type, Stereo 1/4-inch phone typePower SupplyAC adaptorPower Consumption11 W (When using the included AC adaptor)
*Approximate power consumption when playing the piano at medium volume: 6 W
Power consumption when sound has not been played after power-on: 5 WACCESSORIESAccessoriesQuick Start
Leaflet "USING THE UNIT SAFELY"
AC adaptor
Power cord
Music rest
Damper pedal (DP-2)OPTION (SOLD SEPARATELY)Option (sold separately)Dedicated stand: KSFE50
Dedicated pedal board: KPD-70
Keyboard stand: KS-11Z, KS-13, KS-20X
Damper pedal: DP series
Expression pedal: EV-5
Headphones
