KEYBOARDKeyboard61 keys (with velocity)SOUND GENERATORMaximum Polyphony256 voices
* Varies according to the sound generator loadParts8Tones1,600 tones or greater
55 Drum kits or greaterExpansionEXZ World Expansion Series
* The expansion are rewritable internal sound generator memory.
You can download data from the Roland Cloud and write it via a USB flash drive into the internal memory.
Maximum number of Expansions: 3
* Depends on size of Expansion titlesSample ImportAudio file: WAV
File format: 44.1/48 kHz, 16/24 bits
Approximately 12 minutes of samples can be used in total.
Up to 3 minutes of stereo per sample (44.1 kHz, 16 bits)
* Share with Expansion titlesPreset Scene1,600 scenes or greaterUser Scene256Scene RemainYesFavorite100EffectsMulti-Effects: 8 systems, 93 types
Part EQ: 8 systems
Drum Part COMP: 6 systems
Insertion Effect: 1 system, 93 types
Chorus: 10 types
Reverb: 8 types
System EQ: 1 systemSTEP SEQUENCERStep Sequencer8 Tracks (per scene)
Maximum 64 steps
Recording Method: Realtime recording, Step recording, TR-REC
Editing Method: Step editAUDIO FILE PLAYER SECTIONAudio File Player SectionAudio file: WAV, AIFF
File format: 44.1/48 kHz, 8/16/24 bits linear format
Speed/Pitch Control: YesOTHERRhythm patternYesArpeggioYesChord MemoryYesControllersPitch Bend/Modulation lever
Slider x 4
2 x 4 PadsDisplayGraphic LCD (128 x 64 dots with backlight)ConnectorsPHONES jack: Stereo miniature phone type
OUTPUT jacks (L/MONO, R): 1/4-inch phone type
PEDAL jack
USB MEMORY/EXT DEVICE port: Type-A (Storage, MIDI)
USB COMPUTER port: USB Type-C(R) (Class Compliant for Audio and MIDI/ Roland driver for Audio and MIDI)External MemoryUSB flash drive (sold separately)Power SupplyAC Adaptor
USB bus power supply (USB Type-C(R) port)
* External power supply from a USB Type-A port isn't available.Current draw500 mA (AC adaptor)
1,400 mA (USB bus power supply)Power consumption when in OFF mode (when the power automatically turns off)0.2 WAccessoriesStartup Guide
Leaflet “USING THE UNIT SAFELY”
AC adaptor (PSB-5U)
Power cordOptions (sold separately)Keyboard Stand: KS-11Z, KS-13
Pedal Switch: DP-2, DP-10
Expression Pedal: EV-5
