128 scenes x 2 bankUser Scene128Scene RemainYesFavorite128EffectsMulti-Effects: 8 systems, 93 types
Part EQ: 8 systems
Drum Part COMP: 6 systems
Insertion Effect: 1 system, 93 types
Chorus: 10 types
Reverb: 8 types
System EQ: 1 system
Mic Reverb: 8 types
Mic NS/CompVocoderBand: 13
Type: MonoStep Sequencer8 Tracks (per secne)
Maximum 64 steps
Recording Method: Realtime recording, Step recording, TR-REC
Editing Method: Step editAudio File Player SectionAudio file: WAV, AIFF
File format: 44.1/48 kHz, 8/16/24 bitsOtherRhythm PatternYesArpeggioYesDAW ControlYesChord MemoryYesControllersPitch Bend/Modulation lever
Sound Modified knob x 4
Slider x 4
2 x 4 PadsDisplayGraphic color LCD (480 x 272 dots with backlight)ConnectorsHeadphones jack: Stereo 1/4-inch phone type
MAIN OUT jacks (L/MONO, R): 1/4-inch TRS type
Mic Input jack: 1/4 inch phone type/XLR type
External Input jack: Stereo miniature phone type
FOOT PEDAL jacks(HOLD, CONTROL)
MIDI connectors (IN, OUT)
USB MEMORY port: Type-A (Storage)
USB COMPUTER port: USB Type-C(R) (Class Compliant for Audio and MIDI/ Roland driver for Audio and MIDI)External MemoryUSB Flash drive (sold separately)Power SupplyAC Adaptor
USB bus power supply (USB Type-C(R) port)
* External power supply from a USB Type-A port isn't available.Current Draw700 mA (AC adaptor)
2,000 mA (USB bus power supply)Power consumption when in OFF mode (when the power automatically turns off)0.2 WAccessoriesStartup Guide
Leaflet “USING THE UNIT SAFELY”
AC adaptor (PSB-5U)
Power cordOptions (sold separately)Keyboard Stand: KS-G8B, KS-11Z, KS-13, KS-20X
Pedal Switch: DP series
Expression Pedal: EV-5
