* High quality dual channel preamp
* Independent 3 band EQ, Gain and Volume controls for each channel
* Speaker cabinet simulation on/off
*2 different modes for footswitch operation. On/Off or channel A/B
1.DCIN:Connect a DC 9V 300mA centre pin negative power supply2.INPUT:Connect your instrument directly or the output of your pre, pre-amp effects like Overdrive, distortion, etc.3.OUTPUT:
Connect to a power amp or your amplifier’s effects return.(Highly recommend using a tube amplifier)Different power amplifiers will affect the outcome of the final tone.You can also connect directly to a sound card and activate the speaker cab simulation for recording purposesNote: You can connect your "fx loop" effects, like modulation and time based effects, in between the MOOER preamps output and the input of the power amp (fx return)
*Modes:Delay and reverb effects with tap tempo functionality.*Input:1/4” mono audio jack.(Impedance: 1 meg Ohms)*Output:1/4” mono audio jack(Impedance: 100 Ohms)*Power requirements: AC adapter 9V DC , center negative.(Highly recommend to use Mooer Micro Power.)*Current Draw:300mA*Dimensions:93.5mm(D) x 42mm(W) x 52mm(H)*Weight:160g
